Description
- 5.7-inch colour LCD touchscreen display, 640*480 peak
- 12-channel signals displayed simultaneously
- Software for automatic analysis and diagnostics (interpretation)
- Internal memory: 180 ECG files
- Print width: 112 mm
- Interface: RS232, USB, Ethernet
- Built-in lithium battery
| Display. | 5.6-inch colour LCD touchscreen display, 640 * 480 pixels |
| Number of leads | Simultaneous display of data from 12 leads |
| Interface. | Russian and English language |
| Three types of operating modes | AUTO, MAN, RR ANA |
| Types of manual printing | 6CH，3CH，3CH+1rhy, 3CH+3rhy, test mode |
| Types of automatic printing | 6Tx2, 3×4+3rhy, 3×4+1rhy, 3×4, Average template |
| Sensitivity | AUTO, 2.5, 5, 10, 20, 40（mm/mV ± 5%). |
| Measurement: | HR, PR/QT/QTC interval, P/QRS/T axis, etc. |
| Sampling mode | Real-time sampling, pre-sampling, period sampling and trigger sampling |
| Connectivity | with laser printers, barcode scanners, magnetic card readers |
| Data. | Patient identification, gender, age, weight, specialist and physician data, origin, bed and ward number, blood pressure and hospital information |
| Print width | Roll paper112mm × 20m (30m) |
| Internal memory | 180 ECG files. |
| Analysis | Automatic analysis and diagnostic software (interpretation) |
| Power supply | Built-in rechargeable Li-ion battery 2200 mAh, AC/DC power supply |
| Power supply | 100V-240V (± 10%) ,50/60Hz (± 1Hz) |
| Certification | certified in the USA (FDA certificate) and Europe (CE certificate) |
| Frequency response | 0.05Hz~165Hz (-3dB) |
| Input impedance | ≥50ΜO |
| Device size | 345mm (L) × 300mm (D) × 80mm (H). |
| Weight of the device | 2.5 kg (with battery included) |
| Gross weight | 4.5 kg |
| Warranty | 24 months warranty (for 6 m components) |
