Description
Advantages of the SG1 blood gas and electrolyte analyser:
- Excellent accuracy and reliability;
- Does not require liquid reagents;
- Low cost per study;
- Automatic quality control;
- Convenient portable cards that do not require special storage conditions.
Main features of SG1:
- Portable format;
- Minimum sample volume;
- 4.3-inch 800*480 IPS display with touchscreen;
- Ability to use different cards (electrolytes, blood gases).
| Principle. | Microprocessor analysis |
| Sample type | Arterial or venous blood |
| Sample volume | 90 µl |
| Analysis time | 4 min (right next to the patient) |
| Memory. | 500,000 measurements |
| Operating conditions | Temperature: 5 0С - 32 0С, |
| Display. | 4.3-inch 800*480 IPS display with touchscreen. |
| Printing | Integrated thermal printer with 57 mm paper |
| Battery | 5000mAh lithium-ion battery for 72 hours of operation. |
| Dimensions | LxWxH: 220 x 90 x 52 mm |
| Interface. | Linux, USB, Type-C, barcode reader |
| Weight | 0.9 kg |
The price of the equipment is included:
- Staff training;
- Warranty service: 12 months from the date of commissioning;
- Service support and methodological support during the warranty period;
- After the warranty period has expired, the opportunity to conclude a service agreement - priority in servicing and resolving service issues.
